Description
The MT61K512M32KPA-14:C is a 16Gb (2GB) GDDR6 memory chip. The "MT61K" series denotes Micron's GDDR6 technology, which offers significantly higher data rates and bandwidth compared to GDDR5. The "-14" speed grade indicates a data rate of 14 Gbps (14 GT/s), providing a balance between performance and power efficiency for mid-to-high-range graphics solutions.
🚀 Key Functional Description
High-Speed GDDR6 Interface: This device operates at a data rate of 14 Gbps. It utilizes a high-speed interface optimized for point-to-point connections to a host controller (GPU), ensuring low latency and massive data throughput required for 4K/8K texture rendering and complex 3D modeling.
High Density & Organization: It features a total density of 16Gb (2GB) with a x32 bit interface width. The internal architecture consists of 16 banks, allowing for concurrent operations and efficient memory access.
Dual Channel Architecture: The chip is internally organized as two independent 16-bit channels (2 channels x 512 Meg x 16 I/O), which allows the memory controller to access data more efficiently, reducing latency and improving overall system performance.
Advanced Power Management: It operates at a low core voltage (typically 1.35V), reducing power consumption and heat generation compared to previous generations. It also features On-Die Termination (ODT) for all high-speed interface signals, which eliminates the need for external termination resistors and improves signal integrity.
📋 Technical Specifications Summary
表格
Feature Specification
Part Number MT61K512M32KPA-14:C
Manufacturer Micron Technology
Memory Type GDDR6 SGRAM (Graphics RAM)
Capacity 16Gb (2GB)
Organization 512 Meg x 32 (x32 Interface)
Speed Grade 14 Gbps (14 GT/s)
Voltage 1.35V (Typical VDD)
Banks 16 Banks
Package FBGA-180 (12mm x 14mm)
FBGA Code D9ZPM
💡 Typical Applications
Graphics Cards (GPUs): Used in discrete graphics cards for gaming PCs and workstations to buffer frame data and textures.
Gaming Consoles: Providing high-bandwidth memory for next-generation gaming hardware.
Cryptocurrency Mining: Used in mining hardware (ASICs/GPUs) for high-speed hashing operations.
AI & Machine Learning: Accelerating data processing in edge AI devices and neural network training hardware.
High-Resolution Displays: Supporting 4K and 8K video playback and editing.
