Description
The MT41K512M16VRN-107 AAT:P is an 8Gb (1GB) DDR3L SDRAM component. The "MT41K" series denotes Micron's 1.35V low-voltage DDR3 technology, which offers reduced power consumption compared to standard 1.5V DDR3. The "AAT" suffix indicates that this component is Automotive Grade, qualified for operation across a wide temperature range.
🚀 Key Functional Description
Low Voltage Power Efficiency: This device operates at a core voltage of 1.35V (DDR3L), making it backward compatible with 1.5V systems. This reduced voltage lowers dynamic power consumption, which is essential for thermally constrained automotive and industrial environments.
High Density & Organization: It features a total density of 8Gb (1GB) with a x16 bit interface width. The "512M16" organization allows for efficient data handling in embedded processors and FPGAs.
Automotive Grade Reliability: The "AAT" (Automotive Temperature) designation certifies the component for operation typically between -40°C to +105°C. This ensures stability and data integrity in harsh environments, such as engine control units, digital cockpits, and industrial controllers.
Standard DDR3 Performance: It supports standard DDR3 data rates, with the "-107" speed grade typically corresponding to 1866 MT/s (DDR3L-1866). It includes standard features like 8-bank architecture, on-die termination (ODT), and self-refresh modes.
Feature Specification
Part Number MT41K512M16VRN-107 AAT:P
Manufacturer Micron Technology
Memory Type DDR3L SDRAM (Low Voltage)
Capacity 8Gb (1GB)
Organization x16 (512 Meg x 16)
Speed Grade 107 (Typically 1866 MT/s / DDR3L-1866)
Voltage 1.35V (VDD/VDDQ)
Temperature -40°C to +105°C (Automotive Grade)
Package 96-ball FBGA (Fine-pitch Ball Grid Array)
💡 Typical Applications
Automotive Electronics: Powering infotainment systems, instrument clusters, and ADAS modules.
Industrial Automation: Used in PLCs (Programmable Logic Controllers), motor drives, and HMI panels.
Embedded Computing: Buffering data for ARM-based processors and FPGAs in networking equipment.
Medical Devices: Ensuring reliable operation in diagnostic imaging and patient monitoring systems.
